| Parts |
Standard Repair Times |
Coverage Under Extended Warranty |
| U-beam Assembly |
2 Hours per Assembly |
 |
| Frame Hanger |
2 Hours per Hanger |
|
| Clamp Group (top pad and/or bottom cap) |
1.5 Hours per side |
|
| D-pin Bushing |
0.25 Hour per Bushing |
|
| QUIK-ALIGN Bushing |
0.25 Hour per Bushing |
|
| Air Spring |
One Hour per Air Spring |
|
| Height Control Valve |
One - 0.75 hours |
|
| Shock Absorber |
0.5 Hour per Shock Absorber |
|
| Transverse Torque Rod |
1.5 Hours per Torque Rod |
|
| Longitudinal Torque Rod |
1.0 Hour per Torque Rod |
|
| U-bolt |
1 Hour per Set |
|
