| Parts |
Standard Repair Times |
Coverage Under Extended Warranty |
| Main Support Member Assembly |
1.5 hours per Assembly |
 |
| Frame Hanger |
1 hour per Hanger |
|
| Clamp Group (top pad and/or bottom cap) |
2.5 Hours per side |
|
| QUIK-ALIGN Bushing |
0.25 hour per Bushing |
|
| Air Spring |
One hour per Air Spring |
|
| Height Control Valve |
One - 0.75 hours |
|
| Shock absorber |
0.5 hours per Shock |
|
| Transverse Torque Rod |
1 Rod - 1.5 hours |
|
| Longitudinal Torque Rod |
1 Rod - 1.0 hour |
|
| U-bolts |
1 hour per Set |
|
