| Model |
Capacity
(lbs.) |
Installed1 Weight
(lbs.) |
Site travel2 Rating
(lbs.) |
GVW3
(lbs.) |
GCW
(lbs.) |
| HN 40K |
40,000 |
935 |
55,000 |
73,000 |
160,000 |
| HN 46K |
46,000 |
948 |
60,000 |
80,000 |
190,000 |
| HN 52K |
52,000 |
955 |
65,000 |
80,000 |
245,000 |
1. Installed weight is for 54-inch axle spacing and includes complete suspension, torque rods, axle brackets, shock absorbers and frame brackets.
2. SITE TRAVEL RATING - Operators using vehicles equipped with liftable tag or pusher axles must not exceed published ratings. Ratings are limited to no more than 5% of vehicle operation at speed not to exceed 5 mph. Liftable tag or pusher axles should only be raised (or unloaded) to improve vehicle maneuverability in off-road use or when vehicle is unloaded. Site travel ratings are consistent with published axle manufacturer's limitations. Axle and suspension site travel ratings cannot be exceeded.
3. May be limited by vehicle manufacturer.
